Markets: |
North America,Africa,Eastern Asia,Western Europe |
Different Forms: |
125mm |
Type: |
Metal Rolling&Drawing Machine |
Product Description
Material: Galvanized sheet or colored armor plate
Equipment operation: Automatically
Voltage: AC380/50-60Hz
Number of roller: 11
Thickness of sheet(mm): 0, 4...1.5
Material width(mm): 125
Formed width(mm): 80
Productivity: 0-13m/min
Output /shift (8hs): 5000m
Producing capability: 3500 m2/8hs
Diameter of shaft: 70mm
Dimension of main structure(mm): 3500X1200X1300
Material of rollers: 45# steel
Weight: 1830-2200 kg
Total power(kw): 7.5kw
Driven system: Single
Cutting line: Automatic fly-wheel saw cutter
Power of main molding core: Automatic punching
Liming Stamping Form Machine Manufactured Co., is a leading manufacturer for steel plate coiling machinery, roll-forming and automatic production lines. The products are mainly used in steel structure industry for producing C&Z shape purlin, load-bearing plate of buildings, wall and roof protective structure colorful steel plate, thermal insulation; Colorful decorating and protecting steel plates for high-grade steel structure residences; Environment industry anode plate and kathode plate lines for removing dust; Traffic-transport industry freeway guardrail plate, vehicle roll-forming materials; Logistics. Goods shelf pillar, holding beam; Cable bridge, Cabinet pillar and others collorary thin wall roll-forming materials serials-such as goods shelf board, kinds of cabinet screen plate. Then, it can also supply kinds of line of uncoiler, leveler, slitting recoiler, cut-to-length shear stacker.
Liming has advanced production equipment. Engineering personnel and technicians of Bohai are rich in experience of designing, developing, and manufacturing of machineries, They pay close attention to and keep up with the developing trend of technologies and adopt new technologies in the manufacturing of our machinery products, to keep them competitiveness. The products are characteristic of high efficiency, high flexibility and low production cost.
