| Prod Model: |
JLYA |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Location: |
Guang Dong of China |
| Brand: |
July |
| Manufacture: |
July Industry |
| Model: |
Jlya |
| Size: |
352*310*920 |
| Cylinder: |
63 80 100 125 |
| Pressure: |
0.4mpa-0.7mpa |
| Power: |
Pneumatic Press |
| Contact: |
Sunny Tian |
| Electric Box: |
High Quality |
| Forging Forming Method: |
Mold Forging |
Product Description
Characteristics of four column press:
With pressed air as the power, simple to operate.
Making no noise during standby of the oil hydraulic system, saving the electricity and reducing production cost.
Cylinder stroke adjustable and customized for special request.
Easy to adjust the output, the required pressure can be reached by simply adjusting the pneumatic pressure, easy and convenient.
Safe and human-centered design, comfortable and durable operation.
Allows adding heating modules and temperature controller, as well as forcing transducer additionally.
Available working platform: 500*560*610mm
Application of four column press:
Stamping sign Bending profile
Punching die Die cutting rigid material
Touch-welding profile Squeezing die and forming
Flattening and straightening Riveting and forging
Shaping metal plate Closing assembly
Testing material Riveting joint
|
Model |
JLYA-63 |
JLYA-80 |
JLYA-100 |
JLYA-125 |
|
Max height |
85-365 |
80-360 |
80-360 |
70-370 |
|
Cylinder specification |
Ø63*100mm |
Ø80*100mm |
Ø100*100mm |
Ø125*100mm |
|
Power |
AC220V,50Hz |
AC220V,50Hz |
AC220V,50Hz |
AC220V,50Hz |
|
Driving pressure |
0.4-0.7MPa |
0.4-0.7MPa |
0.4-0.7MPa |
0.4-0.7MPa |
|
Weight |
47kg |
49kg |
67kg |
70kg |
|
Driven pressure |
Theoretical output |
Theoretical output |
Theoretical output |
Theoretical output |
|
0.4MPa |
124Kgf |
201Kgf |
314Kgf |
491Kgf |
|
0.5MPa |
160Kgf |
251Kgf |
393Kgf |
613Kgf |
|
0.6MPa |
187Kgf |
302Kgf |
471Kgf |
736Kgf |
|
0.7MPa |
218Kgf |
352Kgf |
550Kgf |
859Kgf |
