| Prod Model: |
Various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Hengxing |
| Place Of Origin: |
China |
| Price: |
Lowest Price for The Same Parameter |
| Drawing: |
Offer |
| Installation: |
Engineer Oversea Service |
| Spare Parts: |
One Yeat for Free |
| Maintenance: |
We Dispatch Engineer |
| Warranty: |
1 Year |
| Structure: |
Vertical Drier |
| Operational Method: |
Continuous |
| Operation Pressure: |
Atmospheric Dryer |
| Heating Mode: |
Transmission |
| Movement Way: |
Combined |
Product Description
Vertical dryer's structure:
The vertical dryer adopts vertical equipment and steel structure housing, the lining is equipped with heat preservation material to keep warm, in the inner of the kiln, and multilayer high temperature castings have been used and overlapped. In the higher, middle and lower parts, all relevant components have several groups of vibrate, closure, temperature control and intelligent control systems. Water vapor and smoke collected and removed by the whirlwind dust collector installed in the draught fan.
Vertical dryer's principle:
The key technology of vertical dryer is to control the flow rate and residence time of the material in every area of the dryer, making the hot flue gas fully convected, radiated and heat conducted with the material which thus can be scattered in the dryer as far as possible to enlarge the contact area between the hot smoke and the material. At the same time, material drying parameter optimization microcomputer software technology has been adopted to proceed online detection to the material moisture and gas temperature in the preheating zone, stoving zone and drying zone, and adjust the system parameters on line such as heating ability, lead-wind quantity, secondary hot wind distribution, heat supply capacity, material closure capacity and retention time, etc., realizing dynamic optimization balance of the system and improving the heat utilization rate.
Vertical dryer's Advantages:
1.)Innovative design: new-style vertical of drying, the material is free dropping, gas material countercurrent operation, which is integrated gathering heat conduction and thermal radiation into a body .Heat efficiency is up to 93%. The whole process is automatic control, easy operation and maintenance.
2.)Less investment: apply small area, saving 80% of the investment, it is especially suitable for the old-line transformation. It can make use of abandoned or idle kiln, mill, tower, library and horizontal dryer, etc. further reducing the investment.
3.)Widely used: drying clay, slag, fly ash, coal, iron can also be used in mineral processing, chemical, foundry and other industries of material drying.
4.)Long life: the internal components used in all heat-resistant alloy, long life, low failure rat
Technical parameter of vertical dryer:
| Model | HXLG-2200 | HXLG-2600 | HXLG-2800 | HXLG-3200 |
| Capacity(t/h) | 3-5 | 6-8 | 8-10 | 10-14 |
| Drying time(h) | 2-2.5 | 2-2.5 | 2-2.5 | 2-2.5 |
| Moisture before drying | 8-12% | 8-12% | 8-12% | 8-12% |
| Moisture after drying | 1.5-3% | 1.5-3% | 1.5-3% | 1.5-3% |
| Power(Kw) | 18.5 | 22 | 37 | 45 |
| Coal consumption(Kg/h) | 100 | 150 | 180 | 230 |
| Hot air temperature(°C) | 200-260 | 200-260 | 200-260 | 200-260 |
Zhengzhou Hengxing Heavy Equipment Co., Ltd. is a joint stock corporation integrating research and manufacture sale with the targt at the large and medium sized series of heavy equipment for mine machinery, wall materies, formed coal, metallurgy and etc. The company is located at No. 8 Hongye Road, West Hehuan Street, High-Tech Development Zone, Zhengzhou, China.
Since establishment, our company has gathered a group of scientific elites with modernized management system and accurate production as well as independent innovation. Furthermore, our company has realized the computer informationization of management, production, and the CAD and CAPP of production research and process design within our company. Our company is equipped with powerful machines and equipment for machining, forging, rivet welding, and carburization heat processing. At the same time the company has established long-term cooperative relationships with many research institutes from at home and abroad. With advanced technology, we can process and develop new products and promote new technology.
We adhere to the guideline of "survive on high quality, develop by good credit" on the basis of market development and customer service. We have provided better social and economic benefits and attained ISO9001-2000 Certificate. Our products sell very well at home and abroad, enjoying very high appraisement from users.
We would like to offer the most advanced technology, reliable quality, and preferential prices centering on clients. Improving customer satisfaction, we sincerely hope to co-operate with new and old customers, jointly creating the new glorious century.
