| Prod Model: |
TUR/TUL-20 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motor: |
1.5kw-15kw |
| Impeller Number: |
Single-Stage Pump |
| Working Pressure: |
Middle Pressure Pump |
| Influent Type Of Impeller: |
Single Suction Pump |
| Position Of Pump Shaft: |
Horizontal Pump |
Product Description
Close impeller centrifugal pump BS series is with stainless steel motor cover. With sanitayr and cost-effective design, it is ideal for dairy, beverage, food processing, pharmaceutical and fine chemical industries.
Technical specifications
Max. Flow: 40m3/h
Max. Head: 36H(M)
Max. Rev: 3600Min-1
Max. Working temperature: 120C/248oF(CIP/SIP)
Material in contacting with products: SS304/316
Other parts: SS304
Mechanical seal: SIC/SIC/EPDM(standard)
Surface finish: Mirror or satin Polish
Inlet & Outlet: Connection Clamp (Standard)
Design and features
1) Casing manufactured with cold-formed plate. Open impeller and close
2) Impeller manufactured with stainless steel investment casting;
3) Mechanical seal according to DIN 2946L1K;
4) Adjustable stainless steel legs. Pump designed according to 3A sanitary
5) Standards; IEC B35 motors, IP55, F-class insulation, 50Hz.
| POWER | VOLTAGE | POWER | VOLTAGE |
| 0.55 |
| 4 |
|
| 0.75 | 210-230V/50HZ | 5.5 | 360V-400V/50HZ |
| 1.1 |
| 7.5 |
|
| 1.5 | 360V-400V/50HZ | 11 | 630V-690V/50HZ |
| 2.2 |
| 15 |
|
| 3 | 420V-460V/50HZ | 18.5 | 420V-460V/60HZ |
|
| 30 |
|
Donjoy built up in 1993, with registered capital RMB 55, 08 millions. We focus on developing high quality PID process controller, the valve positioner, the flow controller, the valve control unit, high purity process control valve, intelligent self-control valve, high pure pump, Cleaning technology, piping and pressure vessel safety technology, high pure tubing fitting and pipeline accessories. Donjoy's products and technoligy are widely used in biopharmaceutical, food, drink, wine and other industrial fields. Donjoy's innovation solutions meets growing demand in the industry of biopharmaceutical, food and beverage from the whold wold, special the emerging market.
Raw material, processing technology, welding technology, surface treatment from Donjoy have achieved advanced levels of domestic and foreign marekt. Donjoy producing according to ASME BPE, EHEDG, FDA and 3A standard, get certificate of PED-97/23/EC and MD-06/42/EC issued by TUV, 3A issued by 3A organization, TS licence and ISO9001: 2008.
Donjoy With advanced technology, excellent quality and perfect after-sales service system, has been assessed for the national high-tech enterprises, the Provincial Famous Trademark, the Trovincial Science and Ttechnology Enterprises, Innovative Enterprises, Patent Model Enterprises, R & D Center, AAA Credit Enterprises.
Donjoy has been committed to major technological advances, is your trusted business partners!
Technological innovation, rapid development of the market and customer needs are the greatest challenges facing us today.
Faced with these challenges we are confident, because of highly professional products and technological innovation, we will meet the growing demard of market and customer with our better and better products.
