| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 500KG |
| Pay Type: | T/T,Western Union |
| Prod Model: | DIN 1.2316 / AISI 420 / S136 / GB 3Cr17NiMnMo |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: | DIN 1.2316 / AISI 420 / S136 / GB 3cr17nimnmo |
| Thickness: | 150~600 |
| Width: | 305~1200mm or as Required |
| Length: | 2500~4000mm or as Required |
| Package: | Export Standard Packing or Customers' Demand |
| Place Of Origin: | Shenzhen,China |
| Delivery: | 7-30 Days After Deposit |
| Type: | Steel Plate |
| Standard: | BS |
| Certification: | SGS |
| Special Use: | Wear Resistant Steel |
| Stock: | Stock |
| Surface Treatment: | Black or Machined Surface |
| Technique: | Forged |
| Application: | Plastic Mould |
Description:
1.DIN 1.2316/AISI 420/S136/GB3Cr17NiMnMo
2.Hot rolled or forged condition,annealing or Pre-harden , black or machined surface
3.Hardness: ≤229HBS or 32~36HRC
4. Hot rolled technology:EAF+LF+VD
Forged technology: EAF+LF+VD+ESR+Forging +Q T + Machined surface
5.Heat treatment quench:1020-1050°C,oil cooling or quenching liquid colling,hardnessHRC≥45
backfire:temperture(°C): 100 200 300 400 500 600
hardness(HRC): 49 47 46 46 47 32
6.Production leadtime: 7~30 days
7.Chemical composition:
C | Si | Mn | P≤ | S≤ | Cr | Mo | Ni |
0.3-0.43 | ≤1.00 | ≤1.00 | 0.030 | 0.030 | 1.40-1.7 | 0.8-1.3 | ≤1.00 |
8.Compared grades(based on usage):
GB | ASTM | DIN | ASSAB |
3Cr17NiMnMo | 420 | 1.2316 | S136 |
Applications:
Used for making the corrosion resistance and wear resistance of high quaity plastic mould, transport plastic
mould, like PVC and CD mould.
Specifications:
Hot rolled condition | Steel plate(mm) | ||
Thickness | Width | Length | |
14~120 | 225~1200 | 1800~3500 | |
130~195 | 225~1200 | 1600~3500 | |
Forged condition | 150~600 | 305~1200 | 2500~4000 |
