| Prod Model: |
WC67K-160x3200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Force: 1600kn: |
Max Width: 3200mm |
| Application: |
Machinery & Hardware |
Product Description
The whole structure of the hydraulic press brake:
- Welded structure: The stress of the welded parts can be eliminated by vibration; So this forging press gives high accuracy.
- Frame: Consist of right and left wall boards, working table, oil box, slot steel and etc., with high strength
Hydraulic system:
- Adopt integrated hydraulic control system, more reliable
- Consist of motor, oil pump and valve groups
- Be installed at the top of the oil box, which can assure that the cylinder is always full of oil when the slide is moving down at high speed
- Complete working cycle can be realized through the control of hydraulic valve.
- The working pressure at the right side of the wall board can be adjusted by the remote adjustment valve
The main sealing components of the cylinder:
- Imported Japan brand products
Synchro control system:
- Slide syncho system: Adopt steel torsion bar synchro system, simple in structure and high in accuracy
- 2 ends of slide have 2 synchro forks
- Adopt upper die compensation to improve the brake precision
CNC system (Computer Numerical Control):
- The DA-41 control offers a complete solution for conventional press brake applications, including the axes control for 2 axes, the press beam and backgauge and flexible I/O configuration
- Besides those systems from DELEM, CYBELEC products are also available for your choice
Advance technology and procedures:
- This metal machining tool is a kind of steel torsion bar synchro press brake. -Electronic control of back gauges and RAM stroke, data displayed and manual setting
- Process of cylinder and sealing component:
Cylinder: No. 45# steel treated, inner holes fine machined and extruded.
Valve rods: No. 45# steel treated, nickel and phosphorous coated outside.
| Model | Nominal Pressure (kN) | Length of table (mm) | Distance Between Housing (mm) | Throat Depth (mm) | Stroke (mm) | Open High (mm) | Main Motor (kW) | Dimensions
(L x W x H) (mm) | weight (t) |
| 40/2000 | 400 | 2000 | 1600 | 200 | 100 | 335 | 4 | 2100x1110x1990 | 2.8 |
| 40/2500 | 400 | 2500 | 2000 | 200 | 100 | 335 | 4 | 2600x1110x1990 | 3.5 |
| 63/2000 | 630 | 2000 | 1600 | 250 | 100 | 335 | 5.5 | 2100x1285x2185 | 3.8 |
| 63/2500 | 630 | 2500 | 2000 | 250 | 100 | 335 | 5.5 | 2600x1285x2185 | 4.2 |
| 63/3200 | 630 | 3200 | 2600 | 250 | 100 | 335 | 5.5 | 3300x1290x2300 | 5.2 |
| 100/2500 | 1000 | 2500 | 2000 | 320 | 100 | 335 | 7.5 | 2600x1470x2510 | 6.3 |
| 100/3200 | 1000 | 3200 | 2600 | 320 | 100 | 335 | 7.5 | 3300x1470x2520 | 7 |
| 100/4000 | 1000 | 4000 | 3200 | 320 | 150 | 400 | 7.5 | 4100x1470x2520 | 8.8 |
| 100/5000 | 1000 | 5000 | 4000 | 320 | 150 | 400 | 7.5 | 5100x1470x2750 | 11.8 |
| 125/2500 | 1250 | 2500 | 2000 | 320 | 150 | 400 | 7.5 | 2600x1470x2510 | 7.5 |
| 125/3200 | 1250 | 3200 | 2600 | 320 | 150 | 400 | 7.5 | 3300x1470x2520 | 8.2 |
| 125/4000 | 1250 | 4000 | 3200 | 320 | 150 | 400 | 7.5 | 4100x1470x2520 | 9 |
| 125/5000 | 1250 | 5000 | 4000 | 320 | 150 | 400 | 7.5 | 5100x1470x2800 | 12.5 |
| 125/6000 | 1250 | 6000 | 4500 | 320 | 150 | 400 | 7.5 | 6100x1700x2700/235 | 16 |
| 160/2500 | 1600 | 2500 | 2000 | 320 | 150 | 450 | 11 | 2600x1500x2530 | 8.5 |
| 160/3200 | 1600 | 3200 | 2600 | 320 | 150 | 450 | 11 | 3300x1500x2560 | 10 |
| 160/4000 | 1600 | 4000 | 3200 | 320 | 190 | 450 | 11 | 4100x1500x2730 | 12 |
| 160/5000 | 1600 | 5000 | 4000 | 320 | 190 | 450 | 11 | 5100x1500x2960 | 15.5 |
| 160/6000 | 1600 | 6000 | 4500 | 320 | 190 | 450 | 11 | 6100x1790x2725/235 | 19 |
| 200/3200 | 2000 | 3200 | 2600 | 320 | 240 | 460 | 11 | 3300x1700x2560 | 13 |
| 200/4000 | 2000 | 4000 | 3200 | 320 | 240 | 460 | 11 | 4100x1700x2830 | 14 |
| 200/5000 | 2000 | 5000 | 3800 | 320 | 240 | 460 | 11 | 5300x1930x3000/250 | 20 |
| 200/600 | 2000 | 6000 | 4500 | 320 | 240 | 460 | 11 | 6300x2000x3100/250 | 25 |
| 250/3200 | 2500 | 3200 | 2600 | 400 | 240 | 525 | 11 | 3300x1850x3000 | 17 |
| 250/4000 | 2500 | 4000 | 3200 | 400 | 240 | 525 | 11 | 4100x1850x3100 | 18 |
| 250/5000 | 2500 | 5000 | 3800 | 400 | 240 | 525 | 11 | 5300x1850x3100/300 | 25 |
| 250/6000 | 2500 | 6000 | 4500 | 400 | 240 | 525 | 11 | 6300x2000x3170/540 | 32 |
| 300/3200 | 3000 | 3200 | 2600 | 400 | 250 | 555 | 15 | 3300x2050x3200 | 21 |
| 300/4000 | 3000 | 4000 | 3200 | 400 | 250 | 555 | 15 | 4300x2050x3300 | 24 |
| 300/5000 | 3000 | 5000 | 3800 | 400 | 250 | 555 | 15 | 5300x2300x3500/540 | 29 |
| 300/6000 | 3000 | 6000 | 4500 | 400 | 250 | 555 | 15 | 6300x2300x3865/690 | 35 |
We, Shaanxi Haven Equipment & Trading Co., Ltd, is consisted with 2 factories and 1 international trading company, so we can export our products directly at competitive price. To run our business conveniently, we set up our 2 factories in Nantong Industry Zone which is located in the most developed economic area in China and is nearby the Shanghai Sea Port, that will be much helpful to low our export cost.
With experienced engineers and worker, we produce high quality machines and supply good after sale service. In the past years, we are specialized in import and export of machinery and equipment such as machine tools, vehicles maintenance equipments, motors, bearings, hand tools, power tools and industrial materials. Our business scope also includes import and export of technology, contracting overseas projects and engineer training services.
Our products have been exported to more than 30 countries or regions in the world with high quality, We commit ourselves to cooperating with importers and exporters all over the world. We are looking forward to your enquiries and collaboration. Our technicians will assure you of appropriate equipment with reasonable prices and best pre-sale and after-sale services.
Our Business Scope Include: Turning Machines (Lathe), Drilling Machines, Drilling And Milling Machines, Boring Machines, Milling Machines, Machining Centers, Grinding Machines, Tool Grinding Machines, Gear Cutting And Finishing Machines, Planning Machines, Shaping Machines, Slotting Machines, Broaching Machines, Sawing Machines, Cut-Off Machines, Screwing And Threading Machines, Honing Machine, Polishing Machines, Shearring Machines, Press Brakes, Bending Machine, Punching Machine, Iron Worker, Presses, Rolling Machine, Notching Machine, Engraving Machines, Electric Discharging Machine (EDM), etc.
Our target is: High quality, efficient service, reliable honesty.
