Air Hammer (C41-25, C41-40, C41-75)
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
C41-25, C41-40, C41-75 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Mass: 75kgs: |
Max Power: 7.5kw |
| Forging Forming Method: |
Mold Forging |
Product Description
Air hammer have many advantages. Such as reliable performance, operational cleverness ect. It can be used to carryout such processes as drawing upsetting punching, shearing&cutting, forge welding and bending.
The machine are widely used. Users of large, middle or small-sized manufactories may select such model of air hammers byactual requirement to be satisfied with their prducts.
| Item | Parameter |
| Model | C41-25 C41-40 C41-75 |
| Falling max mass | 25Kg 40Kg 75Kg |
| Max blow energy | 275J 530J 1000J |
| Number of strokes | 250min-1 245min-1 210min-1 |
| Hammer' s largest tour | 260mm 250mm 330mm |
| Hammer-centre to the frame | 200mm 235mm 280mm |
| Motor | 2.2KW 4KW 7.5KW |
| Lower surface anvil to guide bottom | 240mm 224mm 300mm |
| Anvil block size | 100× 50mm 120× 50mm 145× 65mm |
| Dimension | 800× 410× 1214mm 1160× 650× 1440mm 1440× 800× 1800mm |
| Anvil Block weight | 250Kg 480Kg 780Kg |
| Hammer weight(excluding Anvil and motor) | 470Kg 820Kg 2000Kg |
| Package size | 1100× 650× 1400mm(1/2) 1280× 750× 1670mm(1/2) 1630× 870× 1975mm(1/2) 520× 400× 810mm(2/2) 880× 880× 400mm(2/2) 960× 810× 910mm (2/2) |
| 20' Contanier Q' ty | 20sets 12sets 8sets |
| Standard Accessories | Optional |
| Working unit, Motor, V-belt, Belt pulley, Protecting cover, Guide, Bolt, Gasket, Nut, Washer, Piston ring for front cylinder | Electric box |
