Prod Model: |
JCX1010 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Suitable To Process: |
Color Steel Plate |
Width Of The Plate: |
1200mm |
Rollers: |
13 Rows |
Dimensions: |
7.7*1.35*1.51m |
Power: |
4+4kw |
Thickness Of The Plate: |
0.2mm-0.9mm |
Productivity: |
8-15m/Min |
Diameter Of The Roller: |
75mm75mm |
Weight: |
About 5.6t |
Forging Forming Method: |
Mold Forging |
Product Description
- Introducation
- This machine is made up of roll forming machine,molding press,cutting machine,PLC computer control and hydraulic system
- The machine is stable,no noise,no shake
- Controlling by computer, PLC display, operation is easy, running is steady and reliable,endurable, maintenance-free
cutting machine is characterized by stable driving, easy operation
hydraulic system use the CDF-10 hydraulic pump, long operating life,no noise


this machine is applies to roof fortification
Flow chart:
Decoilling the sheet--sheet guilding--film covering--roll forming--measure length--cutting the panel--panel to the supporter
Machine Feature:
1.Precise forming
2. High-solid forming stand guarantees the goods and uniform high quality of final productd
3. The operation automatically minimizes the tolerance of cutting length
Products Feature:
1. A stylish and attractive design, giving the apperance of a traditional roof tile.
2. Resistant to frost, heat,hail and gales; 100% waterproof, due to the lateral run-off channel on each sheet for several models.
3.The raw material can be in different color, with elegant and noble looking. It is widely used as the garden like factory, hotel, exhibition, villa,civil construction etc.
Technical Parameters:
Material Spec: colored steel sheet; galvanized steel sheet
Thickness of coil sheet: 0.3-0.8mm
Main Motor Power: 4 kw
Forming Speed: 2.0-3.0m/min
Hydraulic station power: 3kw
Quantity of stand:about 14 or 16 stands
Hydraulic pressure:10-12mpa
controlling system: PLC
Index error of length:10m+2mm
Total weight: about 6 tons
Voltage: 380V 3phase 60 HZ or at buyer's requirement
Material of main equipment
main parameter of roll forming machine |
Suitable to process |
Steel plate |
Width of the plate |
1000mm/1200mm/1250mm |
Rollers |
9-11rows |
Dimensions |
5.8*1.55*1.51m |
Power |
4kw+4kw |
Thickness of the plate |
0.3-0.7mm |
Productivity |
8-10m/min |
Diameter of the roller |
Φ70mm |
Weight |
About 3.4T |
Voltage |
380V 50Hz 3phases |
We are professinal manufacture of Roll Forming Machine, Glazed Tile Forming Machine, Corrugated Tile Forming Machine, C/Z/U purlin machine, Ridge Cap Machine, Sandwich panel producing line, and other assistent equipment such as cutting machine, bending machine, decoiler and stacker. A lot of roll forming machines have saled to Russia, Australia, Suriname, Vietnam, Malaysia, North Korea, Kazakhstan, etc. In these years. We have go into international market.
Our factory take the management tenet "top quality, credit based". We make efforts to improve product technology, accelerate the pace of renewal debase, quality, innovation, development of enterprise spirit for clients to provide satisfactory products and services.
We are the largest professional manufacture in cangzhou. We supply high technic desgin and best service for the wholesaler, trading company and final user. We have advantage of researching new products, after sale engineer available for overseas,
Our price is not the lowest but the valuable for customer, our purpose is help customer using the lest cost to get the highest profit.
