| Prod Model: |
HP-20S/D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
200kn |
| Pressure: |
50MPa |
| Travel: |
200+450mm |
| Weight: |
360kg |
| Forging Forming Method: |
Mold Forging |
Product Description
HP-S/D series manual/electric hydraulic press takes the advantages of small size, simple structure, especially suitable for field and frequent power outages of occasions.
Description
20 Tonne WORKSHOP HYDRAULIC PRESS
Suited to any workshop or garage for general use.
Features
Easy to use and powerful press for most applications
Strong hydraulic cylinder ensures precise pressing during operation
Heavy duty high tensile setting pins with stops
235mm Adjustable horizontal ram position
Heavy duty welded steel fabricated frame
Hydraulic joystick control lever
Fitted with table height winch & pressure gauge
Powerful 2 hp TEFC motor
Pre-Commissioning:
1. Press is run & tested prior delivery
2. Hydraulic oil is included with machine
Includes
Complete with vee blocks
Model | units | HP-20S/D | HP-30S/D | HP-40S/D | HP-50S/D | HP-100S/D |
| capacity | kn | 200 | 300 | 400 | 500 | 1000 |
| pressure | Mpa | 50 | 50 | 60 | 60 | 60 |
| travel | mm | 200+450 | 200+450 | 250+450 | 250+450 | 300+450 |
| Table size | mm | 200*300 | 300*400 | 360*500 | 360*680 | 400*800 |
| dimension | mm | 500*350*1300 | 550*400*1500 | 1000*550*1500 | 1000*600*1750 | 1500*750*2250 |
| weight | kg | 360 | 420 | 480 | 560 | 980 |
The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.
All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
