HP Series Industrial Auto Hydraulic Press Machine (HP-630)
| Price: |
US $ 1/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
HP-630 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
6300kn |
| Pressure: |
31.5MPa |
| Travel: |
400+405mm |
| Weight: |
9500kg |
| Forging Forming Method: |
Mold Forging |
Product Description
HP series hydraulic press are used for assembling, calendaring, tension, bending and punching. The supplied oil of this machine is CNK and CBZ pump from Italy. It could save 60% energy compared with the traditional model. The efficiency increased to 2-3 times. It takes the advantages of small volume, high pressure, simple structure and light weigDescription
630 tonne INDUSTRIAL HYDRAULIC PRESS
Suited for the Industrial workshop, for the repair of axles removal & press fit of bearings & bushings
Features
- Easy to use and powerful press for most applications
- Ideal for the repair of axles, shafts, & press fit of bearings & bushings
- Ram can be repositioned via crank hand wheel, slides left or right
- Ram speed down 8.4mm/sec, returns 6.0mm/sec
- Heavy duty welded steel fabricated frame
- Strong hydraulic cylinder ensures precise pressing during operation
- Fitted with pressure gauge
- Safety overload valve
- Hydraulic joystick control lever
- Powerful TEFC motors
- Heavy duty one piece table plate insert
- Extra heavy duty table support with high tensile setting pins
- Table can be adjusted for height using chains and Hydraulic ram
- Pre-Commissioning:
- 1. Press is run & tested prior delivery
- 2. Hydraulic oil is included with machine
| Model | units | HP-30 | HP-50 | HP-63 | HP-100 | HP-150 | HP-200 | HP-300 | HP-400 | HP-500 | HP-630 |
| capacity | kn | 300 | 500 | 630 | 1000 | 1500 | 2000 | 3000 | 4000 | 5000 | 6300 |
| pressure | Mpa | 25 | 25 | 30 | 30 | 30 | 31.5 | 31.5 | 31.5 | 31.5 | 31.5 |
| travel | mm | 200+270 | 220+405 | 220+405 | 250+405 | 250+405 | 300+405 | 300+405 | 300+405 | 300+405 | 400+405 |
| Table size | mm | 300*400 | 480*360 | 400*500 | 440*980 | 440*980 | 500*980 | 700*1200 | 800*1200 | 900*1200 | 1000*1200 |
| dimension | mm | 1160*550*1600 | 1500*650*1950 | 1500*650*1950 | 1730*730*2250
730*630*960 | 1730*730*2250
730*630*960 | 1940*950*2350
900*800*1060 | 2100*950*2700
1100*1200*1350 | 2300*1000*2900
1100*1200*1350 | 2300*1000*2900
1100*1200*1350 | 2300*1200*2900
1100*1200*1350 |
| weight | kg | 420 | 980 | 1020 | 1220 | 1350 | 2200 | 4200 | 5500 | 6500 | 9500 |
- Includes support plate & V blocks
