Capacity:
2000kn
Pressure:
31.5MPa
Travel:
300+405mm
Weight:
2200kg
Forging Forming Method:
Mold Forging
Power Source:
Hydraulic Pressure
Advantage:
Use Widely
Product Description
· Dealing directly with the manufacture- no middle man! · The most competitive pricing in the market. · High quality control standards, such as ISO, CE · Guaranteed delivery time. · Prompt attention to the customer inquiries. · Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good delivery. · Research and Development to meet the customer and the market need.
Features: The hydraulic press cylinder could move freely to frame, so enlarged the working space. It takes the advantages of convenient and quick operation.
model
units
HP-50M
HP-63M
HP-100M
HP-150M
HP-200M
HP-300M
HP-400M
capacity
kn
500
630
1000
1500
2000
3000
4000
pressure
Mpa
25
25
30
30
31.5
31.5
31.5
travel
mm
220+405
220+405
250+405
250+405
300+405
300+405
300+405
Table size
mm
400*500
400*500
440*980
440*980
500*1000
700*1200
800*1200
dimension
mm
1500*650*1950
1500*650*1950
1730*730*2250 730*630*960
1730*730*2250 730*630*960
1940*950*2350 900*800*1060
2100*950*2700 1100*1200*1350
2300*1000*2900 1100*1200*1350
weight
kg
980
1020
1220
1350
2200
4200
5500
The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.
All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
