| Prod Model: |
914-610 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Use: |
Roof |
| Material: |
PPGI Aluminum |
| Power: |
18.5+7.5kw |
Product Description
MAIN TECHNICAL SPECIFICATION
Size: 8000mm × 2250mm × 1800mm
Total Weight: about 11000KG
Main Motor Power: 18.5KW forming power is 7.5kw ; bending power is 4.0kw; cutting power is 4.0kw; conical power is 3.0kw
Working Speed: Straight sheet: 15m/min
Arch sheet: 13m/min
Sewing: 6m/min
Material of rollers: 45# steel, quenched HRC 58-62
Material of roller shafts: 45# steel, adjusted
Material of cutting blade: Cr12 steel (Taiwan Airline Technique)
Material of curving leaves: stainless steel
Controlling system: PLC
Step of rollers: 13 steps
Feeding Width: 914mm
Effective Width: 610mm
The depth of the groove: 203mm
Thickness of the coil: 0.6-1.5mm
Operating factor of the panel: 66%
Proper span: ≤38m
|
Name |
Usage |
Amount |
|
Decoiler(core shaft and cradle) |
Hold and feed the coils |
1 |
|
Sewing machine |
Assembling the sheets |
1 |
|
Straight sheets cradle |
Plate supporter |
8 |
|
Arch sheets cradle |
Plate supporter |
8 |
|
Straight sheets side cradle |
Plate supporter |
8 |
|
Suspender |
Lifting |
3 |
|
Hanger WITH STEEL LINE |
Lifting |
8 |
|
Clamp(UNIQUE BIG TYPE) |
Bait sheets |
8 |
|
Manual Super pliers |
Bait sheets |
1 |
|
Driving chains |
To roll the gears |
3M |
|
Instruction book |
To guide you how to use the machine |
1 |
|
Manual calculator(electric sensing equipment) |
Measure the length by hand |
1 |
|
Rolling crandle |
To rise and fall the machine |
2 |
