| Prod Model: |
HP-100M |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
1000kn |
| Pressure: |
30MPa |
| Travel: |
250+405mm |
| Table Size: |
440X980 |
| Forging Forming Method: |
Mold Forging |
| Power Source: |
Hydraulic Pressure |
| Advantage: |
Use Widely |
Product Description
· Dealing directly with the manufacture- no middle man!
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good delivery.
· Research and Development to meet the customer and the market need.
Features:
The hydraulic press cylinder could move freely to frame, so enlarged the working space. It takes the advantages of convenient and quick operation.
Description
100 tonne with SLIDING CYLINDER RAM INDUSTRIAL HYDRAULIC PRESS
Suited for the Industrial workshop, for the repair of axles removal & press fit of bearings & bushings
Features- Easy to use and powerful press for most applications
- Ideal for the repair of axles, shafts, & press fit of bearings & bushings
- Ram can be repositioned via crank hand wheel, slides left or right
- Ram speed down 8.5mm/sec, returns 8.0mm/sec
- Heavy duty welded steel fabricated frame
- Strong hydraulic cylinder ensures precise pressing during operation
- Fitted with pressure gauge
- Safety overload valve
- Hydraulic joystick control lever
- Powerful TEFC motors
- Heavy duty one piece table plate insert
- Extra heavy duty table support with high tensile setting pins
- Table can be adjusted for height using chains and Hydraulic ram
-
- Pre-Commissioning:
- 1. Press is run & tested prior delivery
- 2. Hydraulic oil is included with machine
Includes
Includes support plate & V blocks
| model | units | HP-50M | HP-63M | HP-100M | HP-150M | HP-200M | HP-300M | HP-400M |
| capacity | kn | 500 | 630 | 1000 | 1500 | 2000 | 3000 | 4000 |
| pressure | Mpa | 25 | 25 | 30 | 30 | 31.5 | 31.5 | 31.5 |
| travel | mm | 220+405 | 220+405 | 250+405 | 250+405 | 300+405 | 300+405 | 300+405 |
| Table size | mm | 400*500 | 400*500 | 440*980 | 440*980 | 500*1000 | 700*1200 | 800*1200 |
| dimension | mm | 1500*650*1950
| 1500*650*1950
| 1730*730*2250
730*630*960 | 1730*730*2250
730*630*960 | 1940*950*2350
900*800*1060 | 2100*950*2700
1100*1200*1350 | 2300*1000*2900
1100*1200*1350 |
| weight | kg | 980 | 1020 | 1220 | 1350 | 2200 | 4200 | 5500 |
