| Prod Model: |
YK |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Q235, Cast Steel, Channel Steel, Cast Steel |
| Delivery: |
in Time |
| Certificate: |
Passed ISO9001:2008 |
| Quality Control: |
Go Through Five Checks Before Delivery |
| Warranty: |
One Year Warranty Except Wearing Parts |
| Install,Debag And Training: |
Free Installation Guidance and Lines Design |
| Operation: |
Easy and Simple |
| Maintenance: |
Few Time |
| After Sale Service: |
Praised by Our Users |
| Manufacture Standard: |
Accord with Industrial Standard |
| Object: |
Ore |
| Shaft Number: |
Double |
| Condition: |
New |
| Type: |
Mineral Processing & Screening Equipment |
Product Description
Working Principle
The Motor through the V-belt make the exciter eccentric block produce high-speed rotation. The rotary eccentric block produce large centrifugal force to stimulate sieve boxes have a certain amplitude circle movement. The material on surface in the tilt screen generated casting movement continuously by the impulse passed by the sieve box.
Characteristics
1. Novel structure, advanced technical parameters, big processing capacity, high screening efficiency;
2. Easy to maintenance and use;
3. Circular Vibrating Screen with spring steel woven mesh or perforated metal sieve, easy to plug holes;
4. Circular Vibrating Screen with rubber isolation springs, long service life, low noise, stable, etc.
Applicable industries
Chemical industry: Resin, coating, industrial pharmaceutical, paint, such as this.
Metal, metallurgical mining: Aluminum powder, lead powder, copper powder, ore, close powders, electrode powder, manganese dioxide, electrolytic copper powder, electric magnetic materials, polishing powder, refractory, kaolin, lime, aluminum oxide, calcium carbonate, quartz sand, etc.
Pollution treatment: Waste oil, waste water, dyeing wastewater, additives, and carbon characteristics.
|
Model |
Mesh size
(mm) |
Max feed
size
(mm) |
Capacity (m³/h) |
power
(KW) |
weight
(kg) |
Dimensions
(L*W*H)
(mm) |
|
2YK1225 |
4-50 |
400 |
8-60 |
5.5 |
2500 |
3040×1840×800 |
|
3YK1225 |
4-50 |
400 |
10-70 |
5.5 |
2850 |
3040×1840×1200 |
|
2YK1230 |
4-50 |
400 |
12-78 |
7.5 |
3000 |
3390×1900×800 |
|
3YK1230 |
4-50 |
400 |
13-80 |
7.5 |
3600 |
3537×1900×1200 |
|
2YK1237 |
4-50 |
400 |
15-86 |
7.5 |
3600 |
4090×1900×800 |
|
3YK1237 |
4-50 |
400 |
16-90 |
7.5 |
4200 |
4400×1950×1200 |
|
2YK1535 |
5-50 |
400 |
20-125 |
11 |
4890 |
4552×2250×900 |
|
3YK1535 |
5-50 |
400 |
21-125 |
11 |
5700 |
4552×2250×1600 |
|
2YK1545 |
5-50 |
400 |
22-150 |
15 |
5330 |
5400×2250×1600 |
|
3YK1545 |
5-50 |
400 |
22-150 |
15 |
5800 |
5400×2250×1700 |
|
2YK1548 |
5-50 |
400 |
22.5-162 |
15 |
5980 |
5300×2200×860 |
|
3YK1548 |
5-50 |
400 |
22.5-162 |
15 |
6600 |
5752×2200×1600 |
|
2YK1848 |
5-80 |
400 |
25-206 |
15 |
7080 |
6140×2470×1380 |
|
3YK1848 |
5-80 |
400 |
32-276 |
18.5 |
7600 |
6140×2710×1780 |
|
2YK1854 |
5-80 |
400 |
32-312 |
18.5 |
8150 |
6500×2600×1300 |
|
3YK1854 |
5-80 |
400 |
32-312 |
22 |
8840 |
6960×2600×1630 |
|
2YK2160 |
5-100 |
400 |
50-475 |
30 |
9780 |
7300×2950×2000 |
|
3YK2160 |
5-100 |
400 |
50-475 |
30 |
10800 |
7300×2950×2000 |
|
2YK2460 |
5-100 |
400 |
65-550 |
37 |
13600 |
7450×3230×1500 |
|
3YK2460 |
5-100 |
400 |
70-620 |
37 |
15600 |
7450×3230×1910 |
