| Prod Model: |
YSH66 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Die Locking Force: |
66tons |
| Trade Mark: |
Yin Shan |
Product Description
1. Brand: "YIN SHAN"
There are our brand as above photo logos on our machine bodies and operation panels.
2. Suitable for zinc alloy, Pb alloy parts die cast.
3. PLC control
4. Factory set up in 1981 in Ningbo city, China.
With "YIN SHAN" brand hot chamber die casting machines and cold chamber die casting machines. High casting quanlity with precise molds, furnaces and auxiliary machines.
|
Project |
unit |
YSH66 |
|
Die locking force |
KN |
680 |
|
Stroke of moving platen |
mm |
240 |
|
Inner space between the bars (H×V) |
mm |
320×320 |
|
Thickness of die block (Min.-Max) |
mm |
150-350 |
|
Injection force |
KN |
66 |
|
Injection stroke |
mm |
130 |
|
Ejection force |
KN |
66 |
|
Ejection stroke |
mm |
60 |
|
Diameter of shot sleeve |
mm |
50 |
|
Max Projecting area of casting |
cm 2 |
202 |
|
Working pressure of vane pump |
MPa |
12 |
|
Motor power |
KW |
11 |
|
Dosage of fluid metal per shot(Zinc) |
kg |
1.5 |
|
Effective volume of crucible (Zinc) |
kg |
250 |
|
Oil consumption of burner |
kg/h |
1.5-6.0 |
|
Volume of oil tank |
L |
280 |
|
Machine weight |
kg |
3950 |
|
Overall dimensions (L×W×H) |
mm |
3900×1500×2000 |
Hybers Industrial Company is located in Ningbo City, Zhejiang Province of China. We have the import & export certificate with rich experience in international business which it already has become a comprehensive company integrating manufacture, innovation and trade industry.
We are a professional manufacturer and seller of series of production equipment for Powder coating equipment, Waterproof pulverization equipment, our Chongqing DEGOLD machine company has got SGS plant certificate and CE certificate for CM mixer, PCS single screw extruder, ZM bead mill and FS high speed disperser in Feb. &Mar. 2010. Another, we are also in area of alloy Zinc & Aluminium Casting machine. Our clients spread all over the world. Owning foreign and domestic advanced processing equipment and perfect inspection instruments, all of our factories have twenty years' history with rich manufacturing experiences and the ISO9001 Quality Certification had already been got. In recent years, our long-term co-operation customers distribute in Australia, Tunisia, Belgium, South Africa, Chile, Peru, Pakistan, India, Turkey, Egypt, Malaysia, Vietnam, and Taiwan area etc.
To be professional, best-qualified and honest is our eternal service brief! With the first-class product quality, reasonable price and timely satisfying products, we are expecting to cooperate with you on the basis of multi-benefit
