Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Material: |
Q235, Cast Steel, Channel Steel, Cast Steel |
Delivery: |
in Time |
Certificate: |
Passed ISO9001:2008 |
Quality Control: |
Go Through Five Checks Before Delivery |
Warranty: |
One Year Warranty Except Wearing Parts |
Install,Debag And Training: |
Free Installation Guidance and Lines Design |
Operation: |
Easy and Simple |
Maintenance: |
Few Time |
After Sale Service: |
Praised by Our Users |
Manufacture Standard: |
Accord with Industrial Standard |
Type: |
Ore Grinder |
Product Description
1. Application of the ceramic ball mill
The small ceramic ball millusing the intermittent operation of the drywet method, feldspar, quartz, clay, minerals and
Other raw materials for the fine grinding. Pay-per mill. Batch type ball mill (ceramic ball) is mainly used in mixing, grinding,
Uniform fineness of the product, to save power. Both dry grinding can also be wet.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
2. The main purpose of the ceramic ball mill Intermittent ball mill is the material to be broken, and then to smash the key equipment. The ball mill is widely used
In cement products, new building materials, refractory materials, fertilizer, ferrous and nonferrous metal processing
And glass ceramics production industry, a variety of ores and other grind-able materials dry or wet grinding.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
3. Ceramic ball mill working principle
Intermittent ball mill is composed by feeding part, discharging part, turning part and driving part (reducer, small transmission
Gear, motor, electric control) the main part. The hollow axis adopts the cast steel, lined with removable, rotary gear adopts
Casting hobbing process, the body inlaid cylinder liner wear, has good wear resistance. The machine running smoothly,
Reliable work.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
4. Features of ceramic ball mill:
1. Large application range, simple structure and convenient maintenance.
2. Large capacity and continuous work are very obvious.
3. Barrel lining and grinding media can apply various abrasive materials.
4. Installation and adjustment are very convenient and easy to be operated.
Specification |
Cylinder size
(mm) |
Output size(mm) |
Weight of loading(t) |
Speed of bucket(r/min) |
Power(KW) |
Piece Weight(kg) |
0.2T |
Φ910×1120 |
0.075-0.89 |
0.2 |
35 |
2.2 |
1910 |
0.5T |
Φ1200×1420 |
0.075-0.4 |
0.5 |
31.45 |
4 |
2500 |
1T |
Φ1400×1800 |
0.075-0.4 |
1 |
27 |
7.5 |
3000 |
1.5T |
Φ1800×2100 |
0.075-0.4 |
1.5 |
23 |
11 |
4500 |
2.5T |
Φ2200×2200 |
0.075-0.4 |
2.5 |
20 |
18.5 |
6500 |
3T |
Φ2200×2600 |
0.075-0.4 |
3 |
20 |
22 |
7000 |
5T |
Φ2500×3000 |
0.047-0.4 |
5 |
16 |
37 |
13000 |
8T |
Φ2800×3400 |
0.047-0.4 |
8 |
13.8 |
45 |
19000 |
10T |
Φ2800×4000 |
0.047-0.4 |
10 |
13.8 |
55 |
20000 |
15T |
Φ3000×5000 |
0.047-0.4 |
15 |
13 |
75 |
28000 |
18T |
Φ3100×5000 |
0.047-0.4 |
18 |
12 |
90 |
28500 |
20T |
Φ3200×5800 |
0.047-0.4 |
20 |
13 |
90 |
29900 |
30T |
Φ3400×6500 |
0.047-0.4 |
30 |
14.2 |
110 |
32000 |
40T |
Φ3600×7000 |
0.047-0.4 |
40 |
13 |
132 |
36000 |
50T |
Φ3800×8000 |
0.047-0.4 |
50 |
11 |
200 |
45000 |
60T |
Φ4000×8500 |
0.047-0.4 |
60 |
.10 |
200 |
52000 |
Henan Xingyang Mining Machinery Manufactory used to be a state-own company. It has more than 30 years experience, who is located in the center of China Henan Zhengzhou, where occupied the important railway, highways, electric power, and postal communications and is the significant economical center in the new Eurasian Land Bridge. And at the same time, it has the advantage of central city of the central plain economic zone, developed science and technology, solid industrial foundation, policy superiority and perfect foundation facilities.
Henan Xingyang Mining Machinery Manufactory acts as the parent company and its branches, mineral processing heavy equipment, crushing and grinding equipment, agricultural machinery, Tibet company. Also we have office in Shanxi, Yunnan, Sichuan, Qinghai, Henan Nanyang City. Our products have export to Middle Asia, Middle East, South East Asia, South Africa, Europe, South America etc. We are stepping into mineral processing, metallurgy, chemical industry, electricity power and environment protecting. Xingyang Kuang People insist the operation principle Quality first, Service first, it enjoys a good reputation in home and abroad. Especially for the crushing equipment, Magnesium metal equipment, and mineral beneficiation plant.
